GENERAL
Frequency Range: 410-470 MHz
Channel Spacing: 250 kHz
Work Mode: Half-duplex
Frequency Stability: 1.5 ppm
Modulation System: CSS
Air Baud Rate: 500bps/11000bps/12500bps/1550 0bps/18000bps
Serial Port Baud Rate: 4800/9600/19200/38400/115200bps
Protocol Type: LoRa
Receive Sensitivity: -120dBm
ELECTRICAL
Power Supply: +8V ~ +32V DC
Received Power: 0.5W
Transmit Power:
- High: 3.3 W
- Low: 2.7 W
PHYSICAL
Size: 126×71×30mm
Weight: 300g
Antenna Connector: TNC, 50 Ohm
Data Connector: Aviation connector to RS232
Indicator: 3 indicators for Power, TX, RX
Button: 2 buttons for channels switching
ENVIRONMENTAL
Operating Temperature: -40℃ to +70℃
Storage Temperature: -40℃ to +85℃
Waterproof & Dustproof: IP66
Shock: Survive from a 2m-drop
Humidity: 100% no condensing
